1) outdoor high speed dome camera 2) 1 year warranty 3) 360 degree rotation 4) CE and FCC etc 5) life time maintainance
Key Feature: * Full aluminum design, can dissipate heat more sufficiently; Black inner-shell makes sharper monitor * Built in OSD menu and support inputting with Chinese or English; Display or set parameter via menu. * Auto-identify various SONY, HITACHI, LG, CNB, SAMSUNG, YOKO, etc, and auto read camera model when power on. * The first designer of wide voltage in domestic, DC12V~AC24V, no need to identify "+" or "-". * Soft address design can alter long-distance ID address code, no need manual dial-up. * Show and Edit title function containing 20 English letters, can independently set the titles for camera itself Preset Position, Patten Scan, Auto-level Scan and Zone display. * Auto flip with vertical 180¡ã in omni-directions, no fade zone * 200 preset positions and titles can be set. * 4 patrol tracking routes, every can insert 32 spots * 4 patterns scan routes and continuous track record of 1000 in action, time of up to 10 minutes£» * 4 auto levels scan routes with left & right spacing; Speed can be set. * Position-indicating function, temperature indicator function (Celsius / Fahrenheit simultaneous display), information display, information inquiry function. * 8 dynamic privacy zone can be setup. * 8 display zones with editable title. * Alarm system with 4input and 2 output channel and support the linkage ( recall preset and various of scan mode. Tracking. Pattern. Auto-level scan) * Auto activation at fixed time, and can auto execute different scans and presets after a given leisure time. * RS485 control, integrated various of protocols, PELCO-D, PELCO-P, KALATEL, AD, PHILIPS, SAE, VCL etc.. * Built-in temperature-controlled heating system and the speed fan * 3 class lightning defend, built in 3000V lightning proof, surge resistant. * IP 66 outer cover with all day protection.
Power input |
DC12V~AC24V (¡À10%) |
Power consumption |
Indoor¡Ü12W,outdoor¡Ü45W |
Image sensor |
1/4 inch SONY SUPER HAD CCD |
Signal mode |
PAL/NTSC |
Preset position |
200 presets, title settable |
Accuracy |
¡À0.1º |
Pan rotation range |
360ºContinuous Rotation, 0.5º-240º/S |
Tilt rotation range |
90ºVertical, 180ºAuto flip, 0.5º-220¡ã/S |
Control method |
RS485/Mancherster/BI-PHASE code |
Protocol |
Pelco-P/D,AD,PHILIPS etc |
Working temperature |
Indoor:0ºC ~ 50ºC,Outdoor:-40ºC ~60ºC |
Ambient humidity |
0-95%Non-condensing |
Shell material |
Aluminum |
Installation |
Wall, Pendant, Pole, Corner |
|
