Specifications:
1) Indoor Mini speed dome camera
2) 10x optical zoom, 500TVL
3) OSD, Privacy Zone
4) Day / Night function
5) 200 presets
Key features:
1) Full aluminum design, black inner ¨C shell, can monitor more sharper.
2) Built in OSD menu and support inputting with Chinese and English; Support 20-bit English character input, Display or set parameter via menu.
3) Auto-identify various SONY, SAMSUNG etc 10*10X integrated camera, super high definition with image reverse function ,and auto read camera model when power on.
4) The first designer of wide voltage in domestic, DC12V~AC24V, no need to identify ˇ°+ˇ± or ˇ°-ˇ°.
5) Hard & Soft address design can alter long-distance ID address code, no need manual dial-up.
6) Show and edit title function containing 20 English letter. independently set the titles for camera itself, as well as Preset position, Pattern scan, Auto-level scan.
7) Auto flip with vertical 180ˇăin Omni-direction, no fade zone.
8) 200 preset positions and titles can be set; 4 patrol tracking routes, every can insert 32 spots.
9) 4 Pattern scan routes, each can record 100 consecutive moves; indication for recording process 00/100....
10) 4 auto levels scan routes with left & right spacing, speed can be set.
11) Position- indicating function, temperature indicator function; information display, information inquiry function.
12) 8 dynamic privacy zones can be setup.
13) Alarm system with 4 input and 2 output channel and support the linkage (recall preset and various scan modes: Tracking, Pattern, Auto-level scan).
14) Auto activation at fixed time, and can auto execute different scans and presets after a given leisure time.
15) Power memory function, automatically recover the original status if power failure.
16) RS485 code, Integrated various protocols, PELCO-D, PELCOP etc.
17) 3 class lightning defend, built in 3000V lightning proof, surge resistant. IP 66 outer cover with all day protection.
|
