The Watec WAT-902H2 ULTIMATE 1/2" Super High Sensitivity Monochrome Camera offers super high sensitivity (near IR) and high resolution in an ultra compact camera. For the ULTIMATE models, Watec WAT-902H2 redesigned the base platform of the 902 series cameras to include higher sensitivity, better S/N ratios, more versatile shutter speed control, and fully adjustable camera functions--including manual gain control and manual back-light compensation.
Watec WAT-902H2 Camera Features:
* 1/2" IT CCD * Resolution: 570 TVL * Min. Illumination: 0.0001 Lux @ F1.4, 0.000033 Lux @ F0.8 * Near IR sensitivity * Fully adjustable camera functions - MGC and manual BLC * Auto Iris connection & BNC connection * Multi-functions: Back light compensation, AGC, shutter speed control, flickerless mode, electronic iris, iris level control * Compact and Lightweight: 3.5 oz. (98g) * CS lens mount * Minimum Illumination (Lux): 0.0003Lux F1.4 (AGC: High), * Automatic automatic gain control (dB) High :5-50 Low5-32, * SNR (dB): 46, * Gradation characteristics: ¦Ã ¨P 0.45; * Watec WAT-902H2 good performance .
Watec WAT-902H2 Specifications:
Model |
WAT-902H2 ULTIMATE (EIA) |
WAT-902H2 ULTIMATE (CCIR) |
Pick-up element |
1/2 inch interline transfer CCD image senso |
Number of total pixels |
811(H) ¡Á 508(V) |
795(H) ¡Á 596(V) |
Number of effective pixels |
768(H) ¡Á 494(V) |
752(H) ¡Á 582(V) |
Unit cell size |
8.4¦Ìm(H) ¡Á 9.8¦Ìm(V) |
8.6¦Ìm(H) ¡Á 8.3¦Ìm(V) |
Synchronizing system |
Internal |
Scanning system |
2:1 interlace |
Video output |
Composite Video, 1Vp-p, 75ohms, unbalanced |
Resolution (H) |
570TVL (Center) |
Minimum illumination |
0.0001lx F1.4 |
S/N |
More than 50dB (AGC=5dB,¦Ã=1.0) |
AE mode |
Fixed |
1/60, 1/100 sec. |
1/50, 1/120 sec. |
1/250, 1/500, 1/1000, 1/2000, 1/5000, 1/10000, 1/100000 sec |
EI |
1/60 - 1/100000 sec.
1/100 - 1/100000 sec.
|
1/50 - 1/100000 sec.
1/120 - 1/100000 sec. |
AGC |
HI: 5 - 60dB / LO: 5 - 32dB |
MGC |
5 - 60dB |
Gamma characteristics |
¨P0.35(HI) /¦Ã¨P0.45(LO) /¦Ã=1.0(OFF) |
Lens-iris |
Video / DC (EIAJ arrangement, Auto-select) |
Back light compensation |
ON / OFF |
Power supply |
DC+12V¡À10% |
Power consumption |
1.32W (110mA) |
Operating temperature |
-10¡ãC-£«40¡ãC |
Storage temperature |
-30¡ãC-£«70¡ãC |
Operating / Storage humidity |
Less than 95% RH (Without condensation) |
Lens mount |
CS mount |
Weight |
Approx. 98g |
SizeW¡ÁH¡ÁL(mm) |
35.5¡Á36¡Á58 |
|
