The Watec 600CX High-Sensitivity Color Camera is a one-cable image capture system that supports transmission of video and power via a single cable. Moreover, it features EI (electronic iris) control for FL mode.
Watec WAT-600CX Features:
* Service video-out terminal * Electronic iris control for Flickerless mode * AGC (Automatic Gain Control) * Video level switch (100 IRE/75 IRE) * Screw lens mount * White Balance Control * Electronic Shutter * Flickerless Mode * Backlight Compensation * Gamma Correction * Coaxial (video / power transmission); * High resolution, high sensitivity; * White balance control; * Electronic shutter, * Electronic iris; * AGC; * BLC, * Gamma correction.
Watec WAT-600CX Specifications:
Model |
WAT-600CX(NTSC) |
WAT-600CX(PAL) |
Image Sensor |
1/3" CCD |
total pixels |
811(H)*508(V) |
795(H)*596(V) |
Effective Pixels |
768(H)*494(V) |
752(H)*582(V) |
Pixel Size |
6.35um(H)*7.4um(V) |
6.5um(H)*6.25um(V) |
imaging system |
Ye, Cy, Mg, and G complementary color mosaic filters on chip |
Synchronization mode |
internal synchronization |
Scanning system |
2:1 interlaced scanning |
video output |
synthesize,Y/C£º1.0 V(P-P),75¦¸,imbalance |
resolution ratio(H) |
More than 540 TVL(Center) |
minimum illumination |
0.02lx. F1.2(AGC HI) |
S/N |
More than 50dB(AGC=OFF,¦Ã= 1.0) |
AE Mode |
Fixed |
1/60 - 1/100(FL) sec. |
1/50 - 1/120(FL) sec. |
1/1000sec. |
EI |
1/60 - 1/100000 sec.(flicker suppress) |
1/50 - 1/100000 sec.(flicker suppress) |
WB |
ATW(color rolling less), PWB |
automatic gain control |
ON |
HI:0-38dB / LO:0-32dB |
OFF |
0dB |
Gamma Features : |
¦Ã¨P0.45(ON)/¦Ã= 1.0(OFF) |
lens |
Video /DC(EIAJ arrangement,Auto-select) |
Image level |
100IRE(ON)/75IRE(OFF) |
BLC |
ON/OFF |
Power voltage |
DC + 15V(WAT-400RX) |
White defect correction |
Up to 32 pixels |
power consumption |
3.3W(220mA) |
Maximum cable length |
3C-2V,150m |
Operating Temperature |
-10 - +50¡æ(Frost-free knot) |
Storage Temperature |
-30 - +70¡æ(Frost-free knot) |
Work /Storage humidity |
Lower than 95£¥RH |
Mount |
CS (Adjustable back focus) |
Weight |
About 140G |
|
