Watec sets high standards for all their CCTV products, and the Watec W-01CDB3 board camera is no exception. With its ultra compact form and in the absence of an enclosure, the W-01CDB3 is the ideal camera for professional covert and custom video installations. Despite being small, Watec was able to incorporate into it a wealth of electronic picture controls including an advanced shutter speed, white balance and AGC. These will assist the camera in maintaining optimum image quality in a variety of lighting and scene situations. You'll also appreciate the camera's CS lens mount, so you can easily pair it with industry standard CCTV lenses.
Watec W-01CDB3 board camera Features:
* Ultra compact, enclosure-free board camera, suitable for covert and custom video applications * Excellent picture quality with 1/3" CCD and 450 TVL of resolution * Good low light performance with 1.5 low lux rating * CS lens mount, compatible with industry standard CCTV lenses * High resolution; * Automatic white balance; * DC12V; * Electronic iris, electronic shutter; * WB; * AGC; * Video amplitude switch; * CS lens mount; * Video / DC auto iris.
Watec W-01CDB3 board camera Specifications:
Model |
WAT-01CDB3(NTSC) |
WAT-01CDB3(PAL) |
Image Sensor |
1/3" CCD |
total pixels |
811(H)*508(V) |
795(H)*595(V) |
Effective Pixels |
768(H)*494(V) |
752(H)*582(V) |
Pixel Size |
6.4um(H)*7.5um(V) |
6.5um(H)*6.3um(V) |
imaging system |
Ye, Cy, Mg, and G complementary color mosaic filters on chip |
Synchronization mode |
internal synchronization |
Scanning system |
2:1 interlaced scanning |
video output |
synthesize,Y/C£º1.0 V(P-P),75¦¸,imbalance |
resolution ratio(H) |
More than 450 TVL(Center) |
minimum illumination |
1.5lx. F1.2 |
S/N |
More than 50dB(AGC=3dB,¦Ã= 1.0) |
AE Mode |
Fixed |
1/60-1/100 sec. |
1/50-1/120 sec. |
1/250,1/500,1/1000,1/2000,1/5000,1/10000,1/20000,1/50000 sec. |
E1 |
1/60-1/100000 sec. |
1/50-1/100000 sec. |
WB |
ATW, Preset(3200K, 5100K,8200K) |
automatic gain control |
3-24dB |
Gamma Features : |
¦Ã¨P0.45 |
lens |
Video /DC |
Image Level |
100IRE / 75IRE |
Mirror image |
On/Off |
Power voltage |
DC + 12V¡À10% |
power consumption |
1.2W(100mA) |
Operating Temperature |
-10 - +40¡æ(Frost-free knot) |
Storage Temperature |
-30 - +70¡æ(Frost-free knot) |
Work /Storage humidity |
Lower than 95£¥RH |
Mount |
CS |
Weight |
About 35G |
|
